Eva Calor 8.5kw Andrea Inset Pellet Stove
Eva Calor 8.5kw Andrea Inset Pellet Stove
All the convenience of an Eva Calor Pellet Stove to fit any modern environment. Create a unique looking stove by placing it in your choice of surround. All the usual features you’ve come to expect of an Eva Calor pellet stove are present including: digital control and turning on/off of stove; remote control; thermostat; fully removable pellet container, even when the stove is on; pellet level sensor.
The range of pellet inserts is made up of different models, they can be inserted into old fireplaces to optimize, with innovation and technology, an underused space.
The inserts can however be used to create new fireplaces and thanks to the different types: low height, extra large and ductable they cover the majority of power, aesthetic and functionality needs.
Main features
Door front in black silk-screened glass
Forced ventilation
Removable front drawer for loading pellets
5 operating powers
Display with 6-language menu
Cast iron combustion chamber
Removable handle
Safety thermostat
External thermostat preparation
Safety pressure switch
Chronothermostat
Technical features
Power burned: max 9.5 kW - min 3.4 kW
Power output in heating: max 8.5 kW - min 3.1 kW
Energy efficiency class: A+
Efficiency: Pmax 90.0% – Pmin 91.5%
CO value with 13% O2 (%): Pmax 0.005% – Pmin 0.024%
Hourly pellet consumption: max 2.0 kg/h – min 0.7 kg/h
Tank capacity: 15 kg
Heated room size: 140 – 200 m3
Minimum distances from flammable walls: side: 18 cm - top. app.: 5 cm - back: 18 cm - front: 100 cm
Power supply voltage/Freq.: 230V – 50 Hz
Electrical rated power: 380W
Measurements: L 67.9 x D 70 x H 68.1 cm
Minimum hole housing dimensions: L 62 x H 63.5 cm
Weight: 99kg
Stainless steel brazier
Complies with standards: EN14785 - BImSchV II - LRV/VKF
Accessories included
Remote control
Optional
WI-FI module for remote control
Perch
Ecodesign 2022
This product falls within the ECO DESIGN 2022 criteria which establish eco-design requirements, calculation and measurement methods for the purpose of reducing emissions into the atmosphere.
Environmental classification
This product meets the most restrictive environmental regulations and has obtained 5 stars.
SHU – Safe handle use
The SHU symbol indicates that the stove is equipped with a removable handle. A safety measure to avoid accidental and/or involuntary opening of the fire door.
